OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
ASSEMBLY & OPERATION
ACTION
BEFORE OPERATION
Installing the battery pack
Removing the battery pack
Checking the battery condition
NOTE: Fig. A3 only applies for the
battery pack with battery indicator light.
Charging the battery pack
More details can be found in charger's
manual
OPERATION
Attaching pressure cleaning lance to the
power nozzle
NOTE: When attaching, align the
two projections on the lance with the
grooves of the power nozzle as shown
in Fig. B.
NOTE: The highest pressure is 350psi.
It is suitable for removing strong stains.
Attaching the multi-spray nozzle
NOTE: when attaching, rotate the
nozzle left and right to make sure the
nozzle is fully seated into position and
gently pull it to make sure it is locked
into position securely.
Attaching the draw hose to the power nozzle
NOTE: After the draw hose is attached,
check the connection by gently pulling
upon the draw hose. It should not be
pulled off.
Attaching your own water hose (optional)
1. Attach the quick connect adapter
2. Attach the home garden hose with
suitable connectors
NOTE: Except for the draw hose
supplied, you can also connect the
power nozzle to your own water hose
with suitable connectors.
NOTE: Check whether the filter screen
is missing before retightening the hose
adapter. (Fig. T1, T2) When retightening
the hose adapter, please tighten
securely. Otherwise, it may not draw
any water for proper operation.
WARNING: It is not
recommended to connect the
draw hose to your garden hose or your
home tap.
Cordless Portable Power Cleaner
Start
NOTE: At the first use, you need to
empty the air in hose, place the power
nozzle below waist level (<5ft/1.5m)
and set it at high pressure.
Do not start working until the water
goes up along the hose and sprays
FIGURE
out. This could take up to 30 seconds
or more depending on the fresh water
source.
See Fig. A1
Selecting the nozzle pattern
NOTE: Choose a suitable nozzle
See Fig. A2
pattern according to your work.
Spray patterns 0
See Fig. A3
applicable for cleaning, and the spray
pattern with the symbol
suitable for watering.
WARNING: Do not shift the nozzle
See Fig. A3
pattern when the tool is powered
on.
Cleaning
WARNING: Do not connect the
machine to water supplies that
are dirty, rusty, muddy, or corrosive.
(Including window cleaning liquids,
See Fig. B
plant foods, or fertilizers etc.)
NOTE: Not recommended for use with
salt water, immediately rinse with fresh
water for proper maintenance.
Watering
See Fig. C
ATTACHMENT OF
ACCESSORIES
See Fig.
D1, D2, D3
A number of accessories have been supplied with
this product and are required for use in different
applications. Do not attempt to use the product
without a lance or any accessories attached.
1. Soap bottle (WA4036)
Soap bottle provides detergent suds for deeper
cleaning of dirt and debris.
Directly connect to tool or extension lance (WA4012 -
sold separately). (See Fig. J1, J2)
Not for use with the included pressure cleaning
See Fig.
lance.
E, F
Note: Keep the machine connected to water source
when using soap bottle.
2. Brush (WA4048)
Brush for cleaning cars, boats, motorcycles etc.
Directly connect to tool or extension lance (WA4012 -
sold separately). (See Fig. K1, K2)
Not for use with the included pressure cleaning
lance.
o o o o
, 15 , 25 and 40 are
is best
See Fig. G
See Fig. H
See Fig. I1
13
See Fig. I2
EN
