1247004‐GB_v1.1
F.2 CANCELLATIONS
Individual cancellation
To delete a code, move to the position where the code is located and press the C key. The dot
indicating a taken position will disappear. The equipment will emit three short beeps.
To return to the previous menu, move to the ‐‐‐‐‐ position and press the C key.
If no action is performed, the equipment exits the program automatically after a period of 60
seconds and emits two short beeps.
Total reset
Move to any memory position and keep the C key pressed down for more than 5 seconds. The
equipment will emit 10 warning beeps followed by others at a more rapid frequency, indicating that
the operation has been performed.
F.3 TIME CONFIGURATION
Allows the unit's date and time to be configured, enabling the correct management of events.
The event memory stores the date and time of the event, the type of event, the code, the number
and the model of the device. The events can be shown using the Assistant programming tool PLO‐
200.
Display
d_xx
M_xx
A_xx
h_xx
m_xx
If no action is performed, the equipment exits the program automatically after a period of 60
seconds and emits two short beeps.
F.4 RELAY CONFIGURATION
Allows configuration of the relay activation timing, and in relay 4, allows configuration of timing if it
is to be used as an anti‐panic function.
Display Bi‐stable configuration (biES)
r1
r2
r3
r4
To return to the previous menu, move to the ‐‐‐‐‐ position and press the C key.
If no action is performed, the equipment exits the program automatically after a period of 60
seconds and emits two short beeps.
ALARM FUNCTION
This function is only configurable using the PLO‐200 programming tool and is only available on
proximity elements where the alarm function is implemented.
Allows for the enabling of a different relay to that programmed by default, reading the device a
certain number of consecutive times in a maximum time of 5 seconds between each reading.
Example: the proximity element enables relay 1 by default and with the alarm function it will enable
relay 3 on reading the device 4 consecutive times.
Configuration
month
minutes
Impulse configuration (Im__)
Yes
Yes
Yes
Yes
day
year
time
01 – 30 seconds
01 – 30 seconds
01 – 30 seconds
01 – 30 seconds
8
Values(xx)
01 ‐ 31
01 ‐ 12
00 ‐ 99
00 ‐ 23
01 ‐ 60
Anti‐panic configuration
(Al__)
Non
Non
Non
01 – 15 minutes
