Technical information ACCESS-IT UNIT p.28/42

3) SOLO-AI Reader (RS485)

12V DC supply
Note: You can connect up to 2 SOLO-AI with an ACCESS-IT UNIT
(?) Data sheet:
SYT recommended
0.6 mm
2 pairs recommended
Be sure to use the same pair for A and B
Be sure to separate the supply from the RS485 bus
Characteristic: Sensitive connection
Screen: Recommended
To reach 1,200 m, you must fit a 220 resistor between points A and B at each end of the network (see
above).
Attention: The total length must not exceed the recommended distance.
