Technical Specifications - Tunstall Rtx3371 Instructions D'installation Et D'utilisation

n This device is for use at home.
n Power requirements:
n Power supply adapter:
n Real time clock backup battery: Rechargeable Lithium battery
n Range of temperatures:
n Relative humidity:
n Barometric pressure:
n Dimensions (WxLxH):
n Weight:
Radio Transmitter:
n
Operating frequency:
Output power:
Antenna type:
Operational range:
n Radio Transmitter GSM/GPRS:
GSM operating frequency:
GSM output power:
GPRS class:
The internal antenna used for this mobile transmitter must provide a separation distance of at least 20 cm
n
from the body and must not be co-located or operating in conjunction with any other antenna or transmitter.
n This device, including the power supply adapter, is certified to comply with IEC/UL60601-1.
n This device, including the power supply adapter, is tested according to IEC60601-1-2. More detailed
information related to electromagnetic compatibility (EMC) is available upon request.
n Class-B digital apparatus complies with Canadian ICES-003.
n Data integrity and security: The privacy of data transmission with this device is secured by data
encryption and authentication (SSL), and meets authorized standards under the HIPAA.
Year and month of production of this device is printed underneath this symbol.
n
Attention: See instructions for use (This manual).
n
Only dispose the RTX3371 at an appropriate recycle facility for electronics. Ask Tunstall
n
Healthcare for more information.
The frequency band is not harmonized. Use of wireless Bluetooth technology can be restricted in
n
some countries. Contact local authorities for more information.
Tunstall Healthcare declares that this device is in conformance with the European Directive
n
93/42/ECC and 99/05/EC.
RTX3371 User Manual v3.0.indd 9
TECHN IC A L S P E C I F IC AT I O N S
Mains: 100-240 VAC, 50-60Hz, 10W maximum (typical 2.4W), Class
II, No applied part. Only use the original power supply adapter with the
type designation FW7333M/06 or WR9QB1000CCP-N-MED.
Equipment protected by double insulation or reinforced insulation.
CAUTION Risk of electrical shock. Dry location use only.
Alternating current and
Operating: +10°C to +40°C / +50 F to +104 F.
Storage: -10°C to +45°C / +14 F to +113 F.
Transportation: -20°C to +60°C / -4 F to +140 F.
Operating/Storage/Transport: 30% to 75% RH non-condensing.
Operating/Storage/Transport: 700-1060 hPa.
145 x 125 x 75mm / 5.7 x 4.9 x 2.9 inches.
479 g / 17 oz including power supply adapter.
Bluetooth compliance: Version 2.0.
®
2.402 to 2.480 GHz.
1 to 100 mW / Bandwidth: <1MHz.
Internal.
Up to 100 meters (indoor) depending of surroundings.
GSM850: 850 MHz, GSM 900: 900 MHz, DCS1800: 1800 MHz,
PCS1900: 1900 MHz
Up to 2W
Class 10
Direct current.
