Technical Data

20 V BATTERY HEDGE TRIMMER
Nominal voltage
No-load speed (n )
0
Cutting length
Maximum branch thickness
Weight
Sound pressure level (L )
pA
Measured sound power level (L
WA
Max. vibration emission (a )
hw
SUITABLE BATTERIES
Voltage
Capacity
SUITABLE CHARGER
Nominal voltage
Output voltage
Charging time
Operation temperature
Protection Class
Weight
Noise & Vibration
The values given in these instructions have
been measured in accordance with a stand-
ardized measurement procedure and can be
used to compare appliances. It may be used
for a preliminary assessment of exposure.
Warning! The vibration emission
during actual use can differ from the
declared total value depending on the use
of the machine.
160 EN
PE-AHS 20 Li
20 V
2200/min
510 mm
16 mm
2.28 kg
67.3 dB(A) / Uncertainty K = 3 dB(A)
) 82.7 dB(A) / Uncertainty K = 2.11 dB(A)
≤ 2.5 m/s² / Uncertainty K = 1.5 m/s²
PE-AK2, PE-AK4 (not included)
20 V
PE-AK2 (6801240): 2.0 Ah Li-ion battery
PE-AK4 (6801241): 4.0 Ah Li-ion battery
PE1H (not included)
100-240 V ~ 50/60 Hz, 78 W
14.4-20 V , 3.0 A
60 min for PE-AK2
120 min for PE-AK4
10-40 °C
/ II
0.25 kg
Try to keep the stress due to vibration as
low as possible. Reduce vibration stress for
instance by wearing gloves when using the
tool and limiting the work time. All phases of
the operating cycle must be considered (e.g.
standby time and no-load run).

Troubleshooting

Caution! Make sure the appliance is switched off and the battery is removed. Always
wear protective gloves.
Problem Possible cause
Motor does not run
The battery is empty.
Battery does not charge Battery is not properly in-
serted into the charger.
Plug or fuse are faulty.
Hedge trimmer does Blades are blunt or damaged. Contact your customer service for
not cut properly
If the device still does not work, please contact your local HORNBACH store or write an email
to: service@hornbach.com

Disposal

The crossed-out wheeled bin logo
requires the separate collection of
waste electric and electronic equip-
ment (WEEE). Such equipment may
contain dangerous and hazardous substanc-
es. These tools must be returned to a desig-
nated collection point for the recycling of
WEEE and must not be disposed as unsorted
municipal waste. By doing so, you will help to
conserve resources and protect the environ-
ment. Contact your local authorities for more
information.
Solution
Charge the battery.
Insert the battery into the charger
correctly.
Check plug and fuse.
repair. Repairs may be carried out
by an authorised customer service
centre only.
Children must not play with plastic bags and
packaging material, due to possible injury or
danger of suffocation. Store such material
safely or dispose of environmentally friendly.
Remove battery before disposal of the
unit and correctly dispose of them.
Used batteries must be disposed of
properly. Battery selling stores and municipal
collection points offer special containers for
battery disposal.
