12 Wet/dry indicator
In addition to the measured value, the wet/dry indicator
shows the moisture evaluation. This indicator is tuned by
the material characteristics (A, B, C; 01, 02, 03, 04, 05,
06, 07, 08) stored in the measuring device. This evaluation is subdivided into 12
steps and it makes an evaluation of the measured material easier. The display is
to be considered as a general indication and not a final evaluation.
13 Index mode
Index mode is used to rapidly locate moisture with
comparative measurements, without a direct output
of material moisture in %. The output value (0 through
1000) is an indexed value that increases as material
moisture becomes greater. Measurements made in index
mode are independent of material type and particularly
useful with materials for which no characteristics are
stored. When comparative measurements reveal strongly
deviating values, the course of moisture in the material
can be localized quickly. In addition to those materials
with characteristics stored in the measuring device,
index mode makes it possible to measure other building
materials (09 ... 31), refer to the table at the right (See
index mode conversion tables). The displayed value (0
through 1000) serves as the basis.
Activate index mode in your measuring device (Step
13b). In order to determine the degree of moisture in a
type of building material, first find the material number
for the building material to be measured. Following this,
read the measured value from the scale displayed on
the measuring device for index mode. Now determine
the value for the corresponding material number in
the table. If this value has a dark grey background, the
material is to be classified as „wet", values without
coloured background are considered to be „dry".
