6.APPENDIX

6.1 Connection of PCB illustration

(1) Wire control interface diagram and definition
B
A
V
T
G
(2) Controller interface diagram and definition
Sign
Meaning
B 485B
A
485A
V 12V power +
T
NET
G
GND(power-)
