Instruction:
 Pinch-off plier is convenient for copper tubes only. Never use it for steel
tubes as clamp jaws may break.

Never close clamp jaws completely for pinching off.
Instructions for use:
1.
Loosen locking screw with a 4mm hex-wrench.
2. Adjust distance of clamp jaws with adjusting screw.
Clamp jaw
distance
Adjusting
screw
3.
Fasten locking screw.
4. Pinch off tube.
Spare parts:
Clamp jaw set
Item no.: 4665070
Matchcode: 14280-KLEMMBACKEN SET UNTEN/OBEN
Attention:
Exchange clamp jaws always in pairs only as jaw pairs are matched.
Hinweise:
2.
Attention:
Distance of the clamp jaws has to be the double wall
thickness or a little less that the tubes are being pinched
off properly.
1. & 3.
locking
screw
4.
