10.6 Cable glands

CABLE GLANDS SELECTION TABLE
Zone - Gas Cable
gland type
IIC Zone 1 or Zone 2 Barrier
IIB or IIA Zone 1
IIB or IIA Zone 2 With gasket IECEX / ATEX
Tab. 01

11 Technical drawings

The values are in millimeters.
j
428
12
147 130
312
Fig. 04
EXHC
14
Certification Operating
temperature
IECEX / ATEX -60 / +80°C
-76 / 176°F
-60 / +100°C
-76 / 212°F
ATEX -20 / +80°C
-4 / 176°F
30
12
116
Cable Cable glands
part code
Not armored OCTEXB3/4C
Armored OCTEXBA3/4C
Not armored OCTEX3/4C
Armored OCTEXA3/4C
Not armored OCTEX3/4
Armored OCTEXA3/4
Ø 210
Ø 114
132
External Diameter
diameter (mm) under armour
(mm)
13 - 20.2 -
16.9 - 26 -
13 - 20.2 -
16.9 - 26 11.1 - 19.7
14 - 17 -
18 - 23 14 - 17
