Redexim Turf-Stripper 1200 Manuel D'utilisation page 26

Distance between knives:
20mm (0.79")
Plate 1 2 3
→
Row
↓
1 A B B
2 B B B
3 B B B
4 B B B
5 D E E
6 E E E
7
E E E
8 E E E
62x Knife
0x Counterweight
60x Distance bush
4x Bolt M10 x 30
0x Bolt M10 x 35
60x Bolt M10 x 55
0x Bolt M10 x 60
64x Nut M10
60x Wind paddle TS
4x Wind paddle side
Distance between knives:
60mm (2.36")
Plate 1 2 3
→
Row
↓
1 G N J
2 N J L
3 J L N
4
L N J
5 P O K
6 O K M
7 K M O
8
M O K
21x Knife
11x Counterweight
60x Distance bush
0x Bolt M10 x 30
2x Bolt M10 x 35
62x Bolt M10 x 55
0x Bolt M10 x 60
64x Nut M10
60x Wind paddle TS
4x Wind paddle side
4
B
B
B
C
E
E
E
F
353.303.128
353.306.073
406.130.190
804.100.300
804.100.350
802.100.550
802.100.600
830.100.100
468.030.904
468.030.906
4
L
N
J
R
M
O
K
Q
353.303.128
353.306.073
406.130.190
804.100.300
804.100.350
802.100.550
802.100.600
830.100.100
468.030.904
468.030.906
Distance between knives:
40mm (1.57")
Plate 1 2 3
→
Row
↓
1 G H H
2 H H H
3 H H H
4 H H H
5 D E E
6 E E E
7
E E E
8 E E E
31x Knife
31x Counterweight
60x Distance bush
0x Bolt M10 x 30
2x Bolt M10 x 35
32x Bolt M10 x 55
30x Bolt M10 x 60
64x Nut M10
60x Wind paddle TS
4x Wind paddle side
Distance between knives:
80mm (3.15")
Plate 1 2 3
→
Row
↓
1 G L L
2 L L L
3 L L L
4
L L L
5 P M M
6 M M M
7 M M M
8
M M M
16x Knife
16x Counterweight
60x Distance bush
0x Bolt M10 x 30
2x Bolt M10 x 35
62x Bolt M10 x 55
0x Bolt M10 x 60
64x Nut M10
60x Wind paddle TS
4x Wind paddle side
4
H
H
H
I
E
E
E
Q
353.303.128
353.306.073
406.130.190
804.100.300
804.100.350
802.100.550
802.100.600
830.100.100
468.030.904
468.030.906
4
L
L
L
R
M
M
M
Q
353.303.128
353.306.073
406.130.190
804.100.300
804.100.350
802.100.550
802.100.600
830.100.100
468.030.904
468.030.906
26
