Installing the Station

WARNING: Your charging station must be installed by a licensed electrician.
1
Disassemble the front casing by removing the 2 front screws and then separate the
mounting plate by unscrewing the lower screw.
Front casing
Front screws
NOTE
The power supply cable can be inserted from
the rear (a) or from under (b) the station:
- 3/4˝ knockout (a) and (b)
- Remove a single cap
- Strain relief not included
2
Use the mounting plate as a drilling template after determining the input to be used,
either at the rear or under the station.
FLO Home G5 | Installation guide | flo.com | January 2019
Back housing
Lower screw
Mounting plate
a
b
