JETS AND AIR CONTROLS

Jets

All spa jets are individually engineered
to provide a unique hydro-massage.
Depending on the model, your spa will
have a combination of the following jets:
Cyclone Therapeutic:
Positioned to focus on large muscle groups,
these jets deliver a concentrated, high volume
stream of water for a deep massage. Each jet
is fully adjustable, allowing users to set the
water flow to the most comfortable setting.
The nozzle can be rotated to target sore
muscle areas.
Cyclone Turbo Swirl Jets:
Positioned to focus on muscle tension zones,
these jets deliver a spinning V-shaped water
stream for a gentle, pulsating massage. Each
jet is fully adjustable, allowing users to set the
water flow to the most comfortable setting.
Cluster Jets:
Positioned in the shoulder area of the spa,
these jets deliver a penetrating massage to
dissolve tension.
Ozone Jet:
This jet is the entry point for ozone produced
during the automatic filtration cycles, and, as
such, is not adjustable.
NOTE: Ozone production is suspended
when other functions are activated on the
control panel by the spa user.
All full sized jets are adjustable from a fully
open to closed position. It is very important
11
CALIFORNIA COOPERAGE
that you NEVER SHUT ALL FULL SIZED JETS
OFF AT ONE TIME!

Cleaning or Replacing Jets

Hard water can cause calcium/mineral buildup
that can restrict or bind the jets. A jet consists
of a face plate and a nozzle. Rotate these parts
weekly and remove/clean monthly to ensure
free movement.
NOTE: It is not necessary to drain the spa
to clean or remove the jets.
Rotating the jet face plate and nozzle
• Rotate the jet face left and right
(open and closed).
• Return the face plate to the full open
position.
• Turn the jets on to high speed.
• Twist the nozzle left and right
• Rotate the nozzle in the socket.
NOTE: If the jet insert disengages from the
spa housing, see steps to reinstall below.
Cleaning the jets
To remove the jet insert, use the palm of your
hand to exert pressure on the face of the jet.
Turn counterclockwise until the jet 'clicks' .
Gently pull the jet assembly from the housing.
To clean the jet insert and housing, use a
pressurized hose and spray the inside of the
jet. Soak the jet in a diluted spa cleaning
solution, rinse. Wipe the inside of the housing
to remove any debris.
To reinstall the jet, line up the tab on the
backside of the barrel with the groove in the
