New Construction Installation
5 - Connect Wires and Install Knockout Plate
• Run 120VAC electrical wiring to the installation
location.
• Use proper UL-approved connectors to secure wiring
to the Knockout Plate provided in Parts Bag.
• Connect wires as shown in wiring diagram.
1
MASTER
MASTER
ON/OFF
ON/OFF
SWITCH
SWITCH
BLK
BLK
LINE
WHT
LINE
WHT
IN
IN
GRD
GRD
SWITCH BOX
SWITCH BOX
BLACK
WHITE
MASTER
MODE
ON/OFF
SELECT
SWITCH*
SWITCH*
* purchase separately
®
Attach cable clamp to Knockout
Plate. Knockout Plate mounts to
outside of Housing and may be
oriented as desired.
2
Connect wires
BLK
BLK
RED
RED
MODE
MODE
SELECT
SELECT
SWITCH
SWITCH
WHT
WHT
GRD
GRD
RED
GROUND (green or bare)
SWITCH BOX
120 VAC
LINE IN
3
BLK
BLK (Adjustable Level)
RED
WHT
RED
WHT
FAN
FAN
(Rated
Level)
UNIT
UNIT
RECEPTACLE
KNOCKOUT
PLATE
4
Screw from
Parts Bag
SP Ceiling Exhaust Fans
5
