H110M-HDV R3.0 / H110M-HDS R3.0 / H110M-DVS R3.0 / H110M-DGS R3.0
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 Chassis Fan Connector (CHA_FAN1)
5 ATX Power Connector (ATXPWR1)
6 SATA3 Connectors (SATA3_2_3)
7 SATA3 Connectors (SATA3_0_1)
8 USB 3.0 Header (USB3_3_4)
9 USB 2.0 Header (USB_4_5)
10 System Panel Header (PANEL1)
11 Chassis Intrusion and Speaker Header (SPK_CI1)
12 TPM Header (TPMS1)
13 Front Panel Audio Header (HD_AUDIO1)
