Special Accessories - Kärcher BP 4 Deep Well Mode D'emploi

The figures of the following special accessories can be found on page 4 of these instructions.
2.645-148.0 Hose PrimoFlex plus 3/4" -
25m
6.997-359.0 Pump connection piece incl.
check valve, small
6.997-473.0 Connection adapter for
pumps G1
6.997-355.0 Dry run fuse
6.997-357.0 Electronic pressure switch
with dry run fuse
DANGER
To avoid risks, all repairs and replacement of spare
parts may only be carried out by authorized customer
service personnel.
First pull out the plug from the mains before carrying out
any tasks on the machine.
Fault
Pump runs but does not
transport
Pump does not run or sud-
denly comes to a standstill
during operations
Pumping capacity is reducing Suction area blocked
Pumping capacity too low
Spacer foot defective
Our Kärcher branch will be pleased to help you further in the case of questions or faults. See address on the reverse.

Special accessories

Phtalate-free 3/4" garden hose for connecting the submersible pres-
sure pump with the application equipment.
Also available in other lengths and qualities.
Vacuum-resistant connection of the hoses to the pump. For pumps
with G1 (33.3 mm) connection thread and 3/4" and 1" hoses, includ-
ing union nut, hose clamp, flat packing and check valve.
To connect pumps to the interior thread of water connections.
If no more water flows through the pump, the dry run fuse will protect
the pump from damage and automatically turn it off. With G1" (33.3
mm) threaded connection.
Perfect for converting a submersible pressure pump into a domestic
water supply system. With water demand, the pump switches on
and off automatically. If no water flows through the pump, the dry run
protection protects the pump against damage and automatically
switches it off. With G1 (33.3 mm) connection thread.
Troubleshooting
Cause
Air in the pump
Suction area blocked
Water level below minimum water
level
Power supply interrupted
Thermal protection switch in the
motor has switched off the pump
as it was overheated.
Dirt particles have got jammed
into the suction area
Fuse at the switch cabinet has
tripped.
The pumping capacity depends
on the flow height, hose diameter
and hose length.
Mechanical effect on the spacer
foot (fall).
Remedy
Switch the pump on and off several times until fluid
is drawn.
Switch off the pump, pull the mains plug and clean
the intake area.
Immerse the pump deeper into the liquid, if possible.
Check fuses and electrical connections
Switch off the pump, pull the mains plug, allow the
pump to cool down, clean intake area, prevent dry
running.
Switch off the pump, pull the mains plug and clean
the intake area.
Switch off the pump, pull the mains plug, clean the
pump and flush if necessary, operate the safety
switch.
Switch off the pump, pull the mains plug and clean
the intake area.
Keep max. flow height, see technical data. If neces-
sary, select a different hose diameter or hose
length.
Unscrew the defective spacer foot using a hexagon
key (SW6) and replace it (spare part).
– 3
EN 11
