EN
U S E R M A N U A L

TECHNICAL DATA

Parameter Parameter value
description

Product name

Water spillway

Model

UNI_WATER_06

UNI_WATER_08

Standard power AC 230 V 50 Hz /
supply unit AC 12 V 830 mA 10 VA
IP class of power pack IP 44
LED lighting power 3.89 6
IP class of LED panel IP 44
Number of LEDs 60
[pcs / m]
Number of water 1
supply pipes
Diameter of water 32
supply pipe [mm]
Dimensions [mm] 300×115×95 450×115×95
Weight [kg] 1.8 2.5
Model

UNI_WATER_10

UNI_WATER_12

Standard power AC 230 V 50 Hz / AC 230 V 50 Hz /
supply unit AC 12 V 830 mA AC 12V 1,250 mA
10 VA 15 VA
IP class of power pack IP 44
LED lighting power 8.2 12.53
IP class of LED panel IP 44
Number of LEDs 60
[pcs / m]
Number of water 2
supply pipes
Diameter of water 32
supply pipe [mm]
Dimensions [mm] 600×115×95 900×115×95
Weight [kg] 3 4.2

1. GENERAL DESCRIPTION

The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed and
manufactured in accordance with strict technical guidelines,
using state-of-the-art technologies and components.
Additionally, it is produced in compliance with the most
stringent quality standards.
DO NOT USE THE DEVICE UNLESS YOU HAVE
THOROUGHLY READ AND UNDERSTOOD THIS USER
MANUAL
To increase the product life of the device and to ensure
trouble-free operation, use it in accordance with this user
manual and regularly perform maintenance tasks. The
technical data and specifications in this user manual are
up to date. The manufacturer reserves the right to make
changes associated with quality improvement.
LEGEND
The product satisfies the relevant safety standards.
Read instructions before use.
6
The product must be recycled.
WARNING! or CAUTION! or REMEMBER! Applicable
to the given situation (general warning sign).
ATTENTION! Electric shock warning!
Class II protection device with double insulation
(applies to the power supply).
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details may
differ from the actual product.
The original operation manual is written in German. Other
language versions are translations from the German.
2. USAGE SAFETY
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury or even death.
The terms "device" or "product" are used in the warnings
and instructions to refer to do Water spillway.

2.1. ELECTRICAL SAFETY

Applies to the power supply
a) The plug must fit the socket. Do not modify the plug
in any way. Using original plugs and matching sockets
reduces the risk of electric shock.
b) Do not touch the device with wet or damp hands.
c) Use the cable only for its designated use. Never use it
to carry the device or to pull the plug out of a socket.
Keep the cable away from heat sources, oil, sharp
edges or moving parts. Damaged or tangled cables
increase the risk of electric shock.
d) If working with the device outdoors, make sure to use
an extension cord suitable for outdoor use. Using an
extension cord suitable for outdoor use reduces the
risk of electric shock.
e) If using the device in a damp environment cannot be
avoided, a residual current device (RCD) should be
applied. The use of an RCD reduces the risk of electric
shock.

2.2. SAFETY IN THE WORKPLACE

a) Make sure the workplace is clean and well lit. A messy
or poorly lit workplace may lead to accidents. Try
to think ahead, observe what is going on and use
common sense when working with the device.
b) If you discover damage or irregular operation,
immediately switch the device off and report it to a
supervisor without delay.
c) If there are any doubts as to the correct operation
of the device, contact the manufacturer's support
service.
d) Only the manufacturer's service point may repair the
device. Do not attempt any repairs independently!
e) In case of fire, use a powder or carbon dioxide
(CO ) fire extinguisher (one intended for use on live
2
electrical devices) to put it out.
f) Regularly inspect the condition of the safety labels. If
the labels are illegible, they must be replaced.
g) Please keep this manual available for future
reference. If this device is passed on to a third party,
the manual must be passed on with it.

2.3. PERSONAL SAFETY

a) Do not use the device when tired, ill or under the
influence of alcohol, narcotics or medication which
can significantly impair the ability to operate the
device.
b) The device is not designed to be handled by persons
(including children) with limited mental and sensory
functions or persons lacking relevant experience and/
or knowledge unless they are supervised by a person
responsible for their safety or they have received
instruction on how to operate the device.
c) When working with the device, use common sense
and stay alert. Temporary loss of concentration while
using the device may lead to serious injuries.
d) To prevent the device from accidentally switching on,
make sure the switch is on the OFF position before
connecting to a power source.
e) The device is not a toy. Children must be supervised
to ensure that they do not play with the device.
f) If this device is used together with another
equipment, the remaining instructions for use shall
also be followed.
2.4. SAFE DEVICE USE
a) Do not use the device if the ON/OFF switch does not
function properly (does not switch the device on and
off). Devices which cannot be switched on and off
using the ON/OFF switch are hazardous, should not
be operated and must be repaired.
b) Before adjusting, replacing accessories, or storing
the appliance, unplug the appliance from the
power source. This will decrease the possibility of
accidentally switching it on.
c) When not in use, store in a safe place, away from
children and people not familiar with the device who
have not read the user manual. The device may pose
a hazard in the hands of inexperienced users.
d) Keep the device in perfect technical condition. Before
each use check for general damage and especially
check for cracked parts or elements and for any other
conditions which may impact the safe operation of
the device. If damage is discovered, hand over the
device for repair before use.
e) Keep the device out of the reach of children.
f) Device repair or maintenance should be carried out
by qualified persons, only using original spare parts.
This will ensure safe use.
g) To ensure the operational integrity of the device, do
not remove factory-fitted guards and do not loosen
any screws.
h) Do not move, adjust or rotate the device in the course
of work.
i) Clean the device regularly to prevent stubborn grime
from accumulating.
j) Do not cover the air intake and outlet.
k) The device is not a toy. Cleaning and maintenance may
not be carried out by children without supervision by
an adult person.
ATTENTION! Despite the safe design of the device
and its protective features, and despite the use of
additional elements protecting the operator, there is
still a slight risk of accident or injury when using the
device. Stay alert and use common sense when using
the device.
3. USE GUIDELINES
The device is used to create a waterfall effect with LED
lighting within water reservoirs (pond, fountain, etc.).
The user is liable for any damage resulting from
unintended use of the device.
7 EN

3.1. DEVICE DESCRIPTION

1
3
2
3
8
4
5
7
6
1. Body
2. LED lighting
3. Plastic connector
4. Power cord
5. I / O switch (ON / OFF) for LED lighting
6. Power adapter
7. Water pump (not included)
8. Hose / piping (not included)
3.2. PREPARING FOR USE/ DEVICE USE
Position the device such that you always have access to the
power plug. The power cord connected to the appliance
must be properly grounded and correspond to the technical
details on the product label.

USING THE DEVICE

1. Attach the plastic connector to the body of the device.
2. Select the mounting location (even and stable
surface) and install the device so that
• it is properly levelled
• access to all parts of the device and the
accessories is not limited
• free flow and fall of water are ensured.
B
A
10 mm
C
A. Valve
B. Wall
C. Water tank
