9. After the engine starts, immediately disconnect the clip from the vehicle chassis and
then the remove the clip from the battery terminal in that order and clip them back
onto the Instant Power™ storage holders.
10. Recharge the Instant Power™ as soon as possible after use.
RISK OF EXPLOSION.
To prevent sparking, NEVER allow the clips to touch together or to contact the
same piece of metal. Never attempt to jump start a frozen battery.
8.2
The Instant Power™ is a power source for all 12V DC accessories that are
equipped with a 12V accessory plug. Use it for power outages and fishing or
camping trips.
Make sure the device to be powered is OFF before inserting the 12V DC accessory plug
into the 12V DC accessory outlet.
1. Ensure the battery clips are securely on the storage holders.
NOTE: The clips on the Instant Power™ are live and will produce arcing or sparking if
they come in contact with each other. To prevent accidental arcing, always keep the clips
on the storage holders when not using them to jump start a vehicle.
2. Open the protective cover of the DC power outlet on the back of the Instant Power™.
3. Plug the 12V DC device into the DC power outlet, and turn the 12V DC device on (if
required).
4. If the 12V DC device draws more than 15A or has a short circuit, the internal fuse of
the Instant Power™ will blow and disconnect the power to the device. If this occurs, the
fuse must be replaced by a qualified service person. Unplug the device. The blown fuse
only affects the 12V DC socket.
9.

MAINTENANCE INSTRUCTIONS

9.1
After use and before performing maintenance, unplug and disconnect the Instant Power™
(see sections 3 and 4).
9.2
Use a dry cloth to wipe all battery corrosion and other dirt or oil from the battery clips,
cords, and the Instant Power™ case.
9.3
Ensure that all of the Instant Power™ components are in place and in good working
condition, including the plastic boots on the battery clips.
9.4
Servicing does not require opening the unit, as there are no user-serviceable parts. All
servicing should be performed by qualified service personnel.

10. MOVING AND STORAGE INSTRUCTIONS

10.1 Store the Instant Power™ in an upright position.
10.2 Store inside, in a cool, dry place.
10.3 Do not store the clips on the handle, clipped together, on or around metal, or clipped to
cables. The clips on the Instant Power™ are live and will produce arcing or sparking if
they come in contact with each other. To prevent accidental arcing, always keep the clips
on the storage holders when not using them to jump start a vehicle.
10.4 If the Instant Power™ is moved around the shop or transported to another location, take
care to avoid/prevent damage to the cords, clips and Instant Power™. Failure to do so
could result in personal injury or property damage.
10.5 IMPORTANT:
• CHARGE IMMEDIATELY AFTER PURCHASE
• KEEP FULLY CHARGED
Charge the Instant Power™ internal battery immediately after purchase, after every use
and every 30 days.
Powering a 12V DC Device:
The DC power outlet is wired directly to the internal battery. Extended
operation of a 12V DC device may result in excessive battery drain.
Recharge immediately after unplugging the 12V DC device.
Do not use and/or store the Instant Power™ in or on any area or surface
where damage could occur if the internal battery should unexpectedly
leak acid.
6
