LED Display
LED
RED
Operational Modes
Operational Mode
Normal
Test (walk test)
Note:
After power up the detector enters into test mode for a period of 20 minutes (disregarding the DIP Switch Modes
Position).
Transmitter/Receiver Communication link setup
The detector must identify itself to the control panel's receiver by registering its coded message
into the receiver's address memory. This is accomplished by performing the following steps:
1. Set the receiver to Registration Mode.
2. Remove the insulation material from the battery and place it in the battery holder on the PCB
on the right direction (pay attention to the "+" and "–" diagram on the PCB)
3. Send a registration message by closing both of the tamper switches (back and cover) for at
least 3 seconds.
4. Verify that the detector has been identified by the receiver.
Caution Notice
Changes or modifications not expressly approved by Electronics Line may void the user's authority to operate
this equipment.
Simultaneous transmissions from two different units may cause message interference resulting in loss of
information.
The communication quality of this unit may be affected by its surrounding environment. Nearby electrical
equipment may interfere with its normal operation.
The operation of this unit must, therefore, be tested at each installation since its transmission quality may vary
as a result of operational conditions.
Optional Swivel Installation (Not Supplied)
Please follow the instructions below for mounting the detector with the Swivel:
1.
Open the
Wireless PIR Outdoor Detector front cover (Unlock C1, Figure 1).
2.
Release internal base (Unlock I1, Figure 2).
3.
Remove back tamper from the internal base (see the "Changing Back Tamper Position"
paragraph on page Error! Bookmark not defined.) and connect it to S5 (Figure 8, Detail A)
on the Standard Swivel.
4.
Select the mounting installation as follows:
Note:
•
The swivel mount has not been evaluated by UL
•
Ensure that you see the engraved UP mark on the upper front face of the swivel.
Wall Mounting
Insert back tamper wires through the Swivel Wires Passage (Figure 8, Detail B).
1.
Secure swivel to the wall through holes S1, S3, S6 and S8.
2.
State
Steady
Description
Dead time (between detection alarms) is 2.5 Minutes.
Dead time (between detection alarms) is 3 sec.
Description
Indicates ALARM
9
