Technical data

System
RF characteristics
Modulation
Frequency ranges
Transmission/receiving frequencies
Switching bandwidth
Nominal/peak deviation
Frequency stability
AF characteristics
Noise reduction system
AF frequency response
Signal-to-noise ratio at 1 mV
and peak deviation, HDx
THD at nom. deviation and 1 kHz
Overall device
Temperature range
Dimensions Carrying case [mm]
Weight Carrying case with EM 500
Carrying case with EK 500
In compliance with
Receiver
RF characteristics
Receiver principle
Sensitivity (with HDX, peak deviation)
Squelch threshold
Antenna inputs
Antenna length [mm]
Antenna input impedance
AF characteristics
AF output voltage
at peak deviation 1 kHz
AF
AF OUT
Level adjustment
PHONES
wideband FM
518 – 550, 630 – 662, 740 – 772, 790 – 822, 838 – 870 MHz
1280, tunable in steps of 25 kHz
16 switchable fixed frequency memories
32 MHz
± 24 kHz / ≤ ± 48 kHz
≤ ± 15 ppm
Sennheiser
60 – 18,000 Hz
RF
≥ 110 dB(A)
≤ 0.9 %
-10°C ... +55°C
380 x 370 x 70
approx. 3100 g
approx. 2200 g
ETS 300 422, ETS 300 445 (CE), FCC
EM 500
true diversity
< 2.5 µV at 52 dB
0–100 µV, adjustable
2 BNC sockets
Telescopic antennas
50 Ω
XLR-3 connector:
0–40 dB
1 / " (6.35 mm) jack socket:
4
2 x ≥ 100 mW at 32 Ω
HDX
EK 500
non-diversity
Arms S/N
M3 thread
518 – 550 MHz: 130
630 – 662 MHz: 110
740 – 772 MHz: 90
790 – 822 MHz: 90
838 – 870 MHz: 80
3.5 mm jack socket:
balanced: 10 dB
u
unbalanced: +4 dB
u
3.5 mm jack socket:
2 x ≥ 100 mW at 32 Ω
balanced: 10 dB
u
