SPECIFICATIONS

Input
MIC A
AUX
RETURN
TALKBACK A
RETURN
TALKBACK B
IN INSERT
MIC
IN INSERT
MIX
- For Micro, Phantom power supply : 12V or 48V or disabled
- Distorsion : < 0,05% -34 dBu MIC at +4 dBu OUT
- Bandwidth : 10 Hz / -1 dB to 30 KHz / -0,5 dB
- Noise to the input, for Mic : -129 dBu A weighted
- SNR : 90 dBA at nominal level and 102 dBA at clipping
Output
OUT INSERT
MIC
OUT INSERT
MIX
MONITOR
OUT
TALKBACK A
OUT
TALKBACK B
OUT
HEADPHONE
- Limiter setting :
- Bargraph peakmeter : 0 dB at +6 dBu / OUT or Monitor.
- Bargraph peakmeter : 0 dB at -9 dBFs on sound card.
Rami - PJO 555
Type
Connector
XLR Balanced
SUB-D 9
Balanced
SUB-D 15
Balanced
SUB-D 15
Balanced
SUB-D 15
Balanced
SUB-D 15
Balanced
Connector Type
SUB-D 15
Balanced
SUB-D 15
Balanced
SUB-D 15
Balanced
SUB-D 15
Balanced
SUB-D 15
Balanced
JACK 6.35 Unbalanced
* 15 dBu max, clockwise
* Off max, anticlockwise
Impedance Sensitivity
-31 à -60 dBu
200 
-66 pot Mic max
15 K
15 K
15 K
15 K
15 K
Impedance Nominal level
100 
100 
100 
100 
100 
22 
25
Clipping
-17 dBu
0 dBu +20 dBu
+6 dBu +20 dBu
+6 dBu +18 dBu
+6 dBu +18 dBu
+6 dBu +18 dBu
Maximum level
+6 dBu +18 dBu
+6 dBu +18 dBu
+6 dBu +18 dBu
+6 dBu +18 dBu
+6 dBu +18 dBu
+4 dBu +13 dBu
