Subject to modification without notice.
General
AC Power __________ 110–127 V/220–240 V / 50–60 Hz
Power consumption
Active _________________________________ 90 W
Standby ______________________________ < 17 W
Economy power save mode _______________ < 1 W
Dimensions, w × h × d ___________ 265 × 310 × 411 mm
Weight (without speakers) ____________________ 7.6 kg
Amplifier
Output power ________ 2 × 120 W MPO, 2 × 60 W RMS,
6 Ω, 1 kHz,THD 10%
Frequency response _____________ 20–20,000 Hz, ±3 dB
S/N ratio __________________________ ≥ 85 dBA (IEC)
Input sensitivity
AUX/CDR IN L/R (standard level) ________ 1,000 mV
AUX/CDR IN L/R (low level) _____________ 500 mV
MIC ___________________________________ 1 mV
DIGITAL IN __________ 500 mV
Output
Impedance speakers ______________________ ≥ 6 Ω
Impedance headphones ______________ 32 Ω–600 Ω
LINE OUT L/R ________________________ 500 mV
SUBWOOFER OUT ______________________ 2.3 V
CD changer and CD recorder
Number of programmable tracks _________________ 99
Playback
Frequency range _____________ 20–20,000 Hz, ±3 dB
S/N ratio ____________________________ ≥ 98 dBA
Cross talk _____________________ ≤ -75 dB (1 kHz)
Total harmonic distortion _________ ≤ -80 dB (1 kHz)
Digital recording ____________________ equal to source
Analogue recording
Frequency range _____________ 20–20,000 Hz, ±3 dB
S/N ratio playback _____________________ ≥ 88 dBA
Cross talk _____________________ ≤ -65 dB (1 kHz)
Total harmonic distortion _________ ≤ -78 dB (1 kHz)
Laser (CD recorder)
Type ___________________ Semiconductor laser GaAIAs
Wave length ___________________ 775–795 nm (at 25°)
Output power ________ 2.5 mW (Read), 35 mW (Write)
Beam divergence ________________________ 60 degree
Tuner
Wave range
FM ___________________________ 87.5–108.0 MHz
MW, Grid 9 _____________________ 531–1,602 kHz
MW, Grid 10 ____________________ 530–1,700 kHz
Speakers
System __________________________ 3 way bass reflex
Impedance __________________________________ 6 Ω
Woofers
Woofer ______________________________ 1 × 5
wOOx woofer __________________________ 1 × 6"
Tweeter ___________________ 1 × 2", Ferro fluid cooled
Tweeter __________________________ 1 × 1", Polydome
Dimensions, w × h × d ___________ 240 × 350 × 290 mm
Weight _______________________________ 3.9 kg/each
Technical data/General information
(75 Ω)/12–96 kHz
pp
1 / "
4

Environmental information

All redundant packing material has been omitted.We have
done our utmost to make the packaging easily separable
into three mono materials: cardboard (box), polystyrene
foam (buffer) and polyethylene (bags, protective foam
sheet).
Your set consists of materials which can be recycled if
disassembled by a specialized company. Please observe the
local regulations regarding the disposal of packing materials,
exhausted batteries and old equipment.
As an ENERGY STAR ® partner,
Philips has determined that this
product meets the ENERGY STAR
guidelines for energy efficiency.
CAUTION
Use of controls or adjustments or performance of
procedures other than herein may result in
hazardous radiation exposure or other unsafe
operation.
CAUTION
INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
Note:This warning is located inside
the enclosure.
®
