DESCRIPTION
The Azur 100mm & 125mm axial extract fans are suitable for domestic bathrooms and W.C's. The
Azur 125mm & 150mm axial extract fans are suitable for domestic kitchens and utility rooms. They are
available as wall or panel/ceiling mounted models with shutter, timer, humidity and PIR combinations
(100mm model only).
ACCESSORIES (not supplied)
WALL FITTING KIT
A range of 100mm, 125mm and 150mm wall kits are
available for installing into most walls using telescopic
liners supplied.
A. INSTALLATION
IMPORTANT: The fan should only be used in conjunction with fixed wiring.
PANEL/CEILING MOUNTING
1.
For panel/ceiling mounting the fan should be installed into a closed duct protected by an
exterior air grille that must comply with the standard requirements of your country to prevent
access to the fans impeller.
2.
Cut a 105mm diameter hole for 100mm fans, a 130mm hole for 125mm fans or a 155mm
diameter hole for 150mm fans.
3.
Loosen the screw at the bottom of the grille and remove the front grille. Mark the screw
centres through the holes in the fan back plate. Drill, plug and screw into position.
4.
After installation, ensure impeller rotates freely and the shutters can open.
5.
Replace the grille and tighten the retaining screw.
WALL MOUNTING
1.
For wall mounting either cut a 115mm diameter hole for 100mm fans, a 140mm hole for
125mm fans or a 170mm diameter hole for 150mm fans, through the wall and insert the wall
sleeve. Slope the sleeve slightly downwards away from the fan. Cut to length and cement both
ends into position flush with the wall faces.
2.
Loosen the screw in the bottom of the grille and remove the front grille. Mark the screw centres
through the holes in the fan back plate. Drill, plug and screw into position. Fix exterior grille into
position with the louvres positioned downwards. (Note:- The grille must comply with the
standard requirements of your country to prevent access to the fans impeller. The wall kit used
in this installation should provide a minimum ducting length of 100mm from the fans back plate
to the inside of the external grille).
3.
After installation, ensure impeller rotates freely and the shutters can open.
4.
Replace the grille and tighten the retaining screw.
Fan
Size
100mm
125mm
150mm
3
EN
Stock Reference
White
8000000002
8000000026
8000000030
