FUNCTION AND CONTROL ELEMENTS
11
Electronic actuator with
1
connecting cable
2
LED on actuator*
3
Main switch ON/OFF
4
Heating symbol, RED
* The LED on the actuator indicates the position of the step motor.
Red: Motor closed • Green: Motor open • Flashing green: Middle position
4 9
10 5 3
TOUCHPAD CONTROL
5
Cooling symbol, BLUE
6
UP key
7
DOWN key
8
Temperature scale
TOUCHPAD
6
1
7 8
9
Boost key
10
Heating/Cooling/ re-
circulating air/heating
without ventilators/
frost protection key
11
Ventilators
2
