Product Identification; Local Codes; Unpacking; Installation - Desa Tech CHAM55N Manuel D'installation

PRODUCT IDENTIFICATION

4

LOCAL CODES

UNPACKING

INSTALLATION

PRODUCT IDENTIFICATION
Log Grate &
Burner Pan
Figure 1 - Clay Chimenea
Note: Appearance of chimenea may vary depending on models.
LOCAL CODES
Install and use appliance with care. Follow all local codes. In the
absence of local codes, use the latest edition of The National Fuel Gas
Code, ANSI Z223.1/NFPA 54 (U.S.)* or CAN/CSA B149 Installation
Code (Canada)**.
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
**Available from:
Canadian Standards Association
178 Rexdale Boulevard
Toronto, Ontario, Canada M9W 1R3
For more information, visit www.desatech.com
For more information, visit www.desatech.com
Vent Cap
Top
Manual
Gas Valve
Lighting
Port
Base
Stand
UNPACKING
WARNING: Do not remove the data plates at-
tached to this appliance. The data plates contain
important warning and safety information.
1. Carefully remove staples from top of outer wrap carton. Open
flaps and remove upper corrugated stabilizer.
2. Carefully remove clay cap from inside top and set aside.
3. Remove staples from base of carton. Carefully lift outer wrap
over top of contents.
4. Lift clay top straight out of clay base and carefully set aside.
5. Lift iron base stand over top of clay base.
6. Remove corrugated top support, and bags of lava rock, vermicu-
lite, glowing embers, and gas log set carton from inside base.
7. Remove logs, grate, burner, burner pan, and connection kit from
carton. Remove all protective packaging from logs.
8. Check all items for any shipping damage. If damaged, promptly
inform dealer where you bought the product.
Note: Deterioration or damage due to severe weather conditions
such as hail, hurricanes, earthquakes, or tornadoes, or discoloration
due to exposure to chemicals either directly or in the atmosphere, is
not covered by the Limited Warranty on the back of this manual. The
warranty also does not cover the following:
• weather damage caused by not using the protective cover
• chips, cracks, or breakage caused from dropping, dragging, or
hitting chimenea.
The surface of the chimenea naturally contains spaces, surface
cracks, and variations in color and texture. The limited warranty
does not cover such surface imperfections.
INSTALLATION
WARNING: Only a qualified service person must
install gas piping and connect appliance to gas sup-
ply. Follow all local codes.
NOTICE: Installation, service, and repair of this appli-
ance must be performed by a qualified installer,
service agency, company, or gas supplier experi-
enced with this type of gas appliance. Only factory
authorized components listed in these instructions
may be used in accordance with the manufacturer's
instructions and all codes and requirements of the
authority having jurisdiction. Any modifications to
this appliance, or use of unauthorized components
or accessory items will void the manufacturer's war-
ranty, and may result in a hazardous condition.
901918-01G
