installing hardware

a. Connect the slide scanner to a power source.
1. locate the power switch on the lower right side of the scanner. make
sure the scanner is turned oFF.
2.
First before plugging it into the scanner.
3. attach the usB cable to the computer using the stadard usB adapter
end. attach the usB adapter end of the cable to back panel of the
scanner.
Inserting Mounted Slides
attention Before scanning...
make sure there is no filmstrip inside scanner before you insert the slide and
there is no slide inside scanner before you insert the filmstrip.
Please note the slide and filmstrip cannot be put into the
scanner at the same time.
mounted slides
1. insert the slide into the slot on the front of the unit, with the dull (emulsion)
side facing up
Plug the aC adapter into an aC power source
