Reflecta RPS 10M CyberView X5 Manuel D'utilisation page 26

ii. Preview Window Area [Fixed Windows] (Continued...)
a. ejects the film to the left
b. reverses the film one frame to the left
a. advances the film one frame to the right
b. ejects the film to the right
Go to... You can select which frame to move to in the strip
image alignment tool
Frame adjustment tool (taBs) if your film is miss aligned after insertion you can
use these taBs on the ruler to adjust alignment by dragging the taB to align
with the edge of the film frame
You can select the ruler measurement unit "in"-"cm"-"px" by clicking the upper-
left corner.
Toolbar Diagram
Select scan area: more than one selection can be made at a time.
Zoom In: to magnify the image where the cursor is currently located.
the image will be magnified with every click until the maximum multi-
ple (1000%) is reached.
Zoom Out: to reduce the size of the viewed image click the Zoom out
cursor to the desired area, the image will reduce by half with every click
until the lowest multiple (25%) is reached.
Rotate 90 Left: to rotate the image counter clockwise 90 degrees.
Rotate 90 Right: to rotate the image clockwise 90 degrees. Flip
Horizontal: to Flip the image 180 degrees horizontally.
Flip Vertical: to Flip the image 180 degrees vertically.
Revert: discard all modifications and restores the image back to
the original state in preview windows.
