ubbink Robot Clean 1 Instructions D'utilisation

1 Robot Clean 1 Operating Instructions and Parts List
Dear Customer,
Thank you for choosing our product to clean your pool. We hope that you will enjoy using your new robot to maintain your swimming pool for years to come. Before you begin to use
your robot, please take a few minutes to carefully read Operating Instructions.
Again, thank you for choosing our product.
DO NOT ENTER THE POOL WHILE CLEANER IS IN USE
Parts List
Ref. No. Description
1 Floating Power Cord
2 Power Cord Fixing Joint
3 Universal Drain Assembly
4 Top Cover
5 Water-proof Joint
6 Grabbing Clip
7 Motor Mounting Assembly
8 Motor Filtration Cover
9 Filtration Bag Supporting Assembly
10 Wheel Axle Assembly
11 Wheel with Coating
12 Motor
13 Impeller
14 Screw ST3.9*11.6-C-H
IMPORTANT SAFETY INSTRUCTIONS
- Before installing this product, read all safety instructions carefully and keep for later reference.
- Observe all warnings and instructions marked on power supply and cleaner. Failure to follow safety warnings and instructions can result in severe injury or property damage.
- The unit must be supplied through a residual current device (RCD) having a rated residual operating current not exceeding 30 mA. The connection to the branch circuit should be
consistent with the local and national wiring rules and shall be made by a qualified electrician.
- The power supply box of the cleaner must be located at minimum 3.5 meters away from the pool.
- The power supply box of the unit must be securely fixed on the ground or at the wall. Never operate the unit without fixing the power supply box first.
- Keep power supply away from heavy rain or placed in puddles of water
- Do not plug the power supply into a grounded outlet or do not switch the pool cleaner "ON" if it is not fully immersed in water. Operating the cleaner out of water will cause severe
damage and will result in loss of warranty.
- This unit is suitable for cleaning water at temperatures between minimal 5°C and maximal 45°C. However, the recommended optimum pool water temperature is between 22°C
and 32°C.
- Allow the cleaner to remain in the pool for 15 to 20 minutes following the end of its cleaning cycle. This will allow the motors to cool adequately. Do not leave the cleaner in the
pool all the time.
- Always turn the power supply "OFF" and unplug it from the power outlet before removing the cleaner from the pool.
- The cleaner must not be used when people are in the water.
- The unit is designed for use with swimming pools only.
- Mishandling of the unit can result in leakage of lubricants.
- The sealed motor unit and the power supply (transformer) contain no user-serviceable parts. Opening them will automatically VOID your warranty.
- If the supply cord is damaged, it must be replaced by the manufacturer's service agent or a qualified and trained person in order to avoid a hazard.
- The unit is only to be used with the power supply unit provided with the cleaner.
- This unit can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
- Keep small parts and packaging materials away from children. Hazard due to risk of suffocation!
Ref. No. Description
15 Anti-bumping Wheel Assembly
16 Replacement Brush
17 Main Body Base
18 Filtration Bag
19 Control Box
20 Power Cord Socket
21 ON/OFF Switch
22 Power Cord with Plug
23 PCB Board
24 Power Inverter
25 Aluminum Plate
26 Screw ST4.2*8-F-H
27 Driver Board
