CONNECTION AND OPERATING
- Place the device in the desired location at least 1 meter from the nearest obstacle or wall.
- Select the operating mode with the MENU button as shown in the table below. Use the UP and DOWN
buttons to navigate within the menu and press ENTER to select and save the setting.
- The MENU will look like this::
dxxx D Auxx/Soxx D Stxx D Snxx D Spxx D rxxx D Gxxx D bxxx
- Each operating mode requires different settings. The following table summarizes the values to be modified
in each mode:
FUNCTION
DMX control
7 presets with 1 fixed color
3 multi-colour mixing programs
(from abrupt (08) to smooth (10) transitions)
Automatic sound mode without
stroboscope
Automatic sound mode with stroboscope
Custom fixed color RGB
To configure the mode you must first modify the associated SETTING values where they are required (strobe,
sensitivity and/or speed) and then you must press the ENTER button to save the selected value. Finally,
select the MODE and press ENTER again.
- To control this PAR-18L spotlight using the DMX controller, select the DMX channel with a value between
1 and 512 (d001-d512) using the UP, DOWN buttons and press ENTER to save the value.
The following table shows the functions performed by the 7 DMX channels available on this device. You
can switch freely between several channels at the same time.
CH DMX
DMX VALUE
1
2
3
4
5
6
7
- To connect several DMX controlled cascade devices, please note the following connection for XLR
interconnection cables:
- Connect the device to the electricity grid and switch it on.
MODE
d001-d512
Au01 - Au07
Au08 - Au10
So01
So02
r000 - r255
G000 - G255
b000 – b255
FUNCTIONS USING DMX 512 CONTROL CONSOLE
0-255
1-255
1-255
0-255
0-255
0-255
0-255
STROBE SPEED
St00: off
St01: slow
St16: fast
-
St00 - St16
St00 - St16
-
-
-
FUNCTION
DIMMER
STROBE
MACRO
MACRO function speed adjustment
Red DIMMER
Green DIMMER
Blue DIMMER
- 3 -
SETTINGS
SPEED
SENSITIVITY
COLOR CHANGE
Sn00: minimum
Sp01: very slow
Sn16: maximum
Sp16: very fast
-
-
-
Sp01 - Sp16
Sn00 - Sn16
Sn00 - Sn16
-
EN
-
-
-
-
-
-
