PREMASREG DS 2
The mechanical differential pressure switch ⁄ differential pressure monitor PREMASREG
above-atmospheric, differential and below-atmospheric pressures of clean air and other gaseous, non-aggressive non-combustible media in air ducts,
air intake or exhaust devices, as a pressure difference detector or pressure monitor for flow detection at electric heating registers, for monitoring
V-belts and filters, as air pressure deficiency protection, for monitoring fans and air dampers, or as a limit value controller. The switchpoint is
adjusted using the internal precision scale.
These instruments are factory-calibrated. The differential pressure switch DS 2 is supplied including connection set ASD-06 (2 m connection hose,
two pressure connection nipples, screws) and mounting ring DS -MR - K.

TECHNICAL DATA

Switching capacity:
(Contact load)
Contact:
Pressure range:
Housing:
Temperature of medium:
Membrane:
Humidity:
Electrical connection:
Pressure connection:
Mounting:
Protection class:
Protection type:
Standards:
Tests:
FUNCTION

ACCESSORIES

ASD - 06
DS -MR - K
WS-04
PREMASREG ® DS 2 Differential pressure switches with mounting ring, Standard
Type ⁄ WG03B Pressure range (adjustable)
D S - 2 0 5 F 20... 300 Pa
D S - 2 0 5 B 50... 500 Pa
D S - 2 0 5 D 100...1000 Pa
DS-205 E 500...2000 Pa
ACCESSORIES
ASD-06 Connection set (included in the scope of delivery), consisting of
2 connection nipples (straight) made of ABS,
2 m PVC hose (soft, UV-resistant) and 4 screws
ASD-07 2 connection nipples (at 90 degree angle) made of plastic, ABS
WS-04 Weather and sun protection hood, 130 x 180 x 135 mm, stainless steel V2A (1.4301)
5 (0.8) A, 250 V AC
4 (0.7) A, 30 V DC
single-pole potential-free changeover contact,
multi-layer contact, gold-plated (DDC compatible)
see table,
high adjustment accuracy due to individual laser-etched scale for each switch
base: material PC (10 % GF),
colour light grey (similar to RAL 7035),
snap-on lid: material PC, transparent,
cable gland PG 11 with strain relief
–30...+85 °C
silicone, LSR (Liquid Silicon Rubber,
tempered at +200 °C, non-outgassing, LABS-free,
no emission of varnish-adhesion inhibiting substances),
long-term stability of switching points due to trapezoidal bead membranes
< 90 % r. H., non-precipitating air
2
0.14 - 1.5 mm , via terminal screws with torsion protection
with connection nozzles for pressure hose Ø 6 mm
by 4-hole base ring, plastic (included in the scope of delivery),
recommended mounting position:
vertical (pressure connections downward) – factory setting,
horizontal (cap up ⁄ down)
II (according to EN 60 730)
IP 54 (according to EN 60529) with top cover
CE conformity, low-voltage directive 2014 ⁄ 35 ⁄ EU
DVGW (according to DIN 1854), VDE 0630, EN 61058,
directive on gas devices 2009 ⁄ 142 ⁄ EU, CE 0085 A P 0918
Contact 1 - 2 breaks when pressure ⁄ differential pressure rises to the preset value.
Contact 1- 3 closes when pressure ⁄ differential pressure drops and can be used as signal contact.
Connection set (nipple straight) – (included in the scope of delivery)
Mounting ring (included in the scope of delivery)
Weather and sun protection hood, 130 x 180 x 135 mm, aus stainless steel V2A (1.4301)
Operating Diff. approx.
(0.2...3.0 mbar) 0.1 mbar ± 15 %
(0.5...5.0 mbar) 0.2 mbar ± 15 %
(1.0...10.0 mbar) 0.4 mbar ± 15 %
(5.0...20.0 mbar) 1.0 mbar ± 15 %
® DS-2 with 4-hole plastic base ring is used for monitoring
Max. Pressure Item No.
5000 Pa (50 mbar) 1302- 4026- 0000- 000
5000 Pa (50 mbar) 1302- 4022-000 0-000
5000 Pa (50 mbar) 1302- 4027- 0000- 000
5000 Pa (50 mbar) 1302- 4028-0000- 000
7100- 0060-3 000-000
7100- 0060- 7000-000
7100- 0040- 7000- 000
Rev. 2021 - V17
