The speakers are not suitable for installation with an arrester cable. Do not attach any safety arrester cable
to the rear of the device!
Inspection of the installation (for commercial/public use):
An authorized expert must inspect the installation (including the electric connection) before first-time
operation and after the installation has been changed significantly. Have the installation inspected once a
year by an authorized expert.

9. Connection

The wiring is an electric installation. The product connections must be carried out by a qualified expert (i.e.
electrician), who is familiar with all applicable regulations!
If you do not have the required expert knowledge, do not install the product yourself, but have it installed
by an expert.
Connect the speakers to appropriate speaker outputs of audio amplifiers only.
Make sure the power indicated under technical data corresponds to the parameters of the connected
amplifier. Otherwise the speaker and/or amplifier could get damaged.
The amplifier to which to connect the speakers must be disconnected from the power supply when
performing the connections (pull the mains plug!).
Connect the product with dry hands only.
The speaker cables must not be squeezed or damaged by sharp edges.
Strip the wires not to be used before connecting the speakers to the amplifier. Otherwise there is a
risk of electric shock or risk of short circuit!
Power setting
Connection cable
colour
Polarity
22
Input voltage 100 V
1 W 2 W
red yellow
(+) (+)
4 W 8 W
green blue
(+) (+)
15 W ----
white black
(+) (-)
