GETTING TO KNOW YOUR SHARK IQ ROBOT™
Charge Indicator Lights
Error Indicator Light
Front Bumper
Clean Button
Dust Bin
Release Tabs
Debris Discharge
Opening
Cliff and Boundary Sensors
Side Brush
Battery Door
Self-Cleaning
Brushroll
Charging Contact
s h a r kc l e a n . c o m
Wi-Fi Indicator Light
!
Dock Button
Navigation
Module
Power Button
Docking Sensor
Front Caster
Wheel
Drive Wheel
Brushroll Door
Robot Dust Bin
and Filter
GETTING TO KNOW YOUR SHARK IQ ROBOT™
Base Dust Bin
FRONT
Release
Fill Window
Dust Bin
Empty Button
Debris Intake
Charging Contact
BACK
Pre-Motor
Filter Housing
Charging Base
Charger Cord Wrap
Base Dust Bin
Charging Base
Charging Contact
Base Dust Bin
Post-Motor Filter
Access Door
Power Cord
Connection
