1 - GENERAL SPECIFICATIONS
Angénieux OPTIMO 56-152
Zoom ratio
Horizontal focal length
Vertical focal length:
Maximum Aperture
Minimum Object Distance (MOD)
Image coverage
Weight
Front Diameter
Iris scales
Angular rotation of iris ring
Iris gear drive
Zoom scales
Angular rotation of zoom ring
Zoom gear drive
Focus scales
Angular rotation of focus ring
Focus gear drive
Angular field of view (for film size: 22x18.6mm)
Horizontal focal length
Vertical focal length
Horizontal angular field of view
Vertical angular field of view
Object size at MOD
10
OPTIMO 56-152
1 - GENERAL SPECIFICATIONS
2.7x
28 - 76mm
56 - 152mm
T:4 – f/3.6
0.63 m – 2'1''
22 x 18.6mm
2.2kg – 4.8 lbs
114 mm
2 opposite scales, whole and 1/3 stop marked T:4 – T:22
90 degrees
105 teeth, pitch 32
2 opposite scales
170 degrees
105 teeth, pitch 32
2 opposite scales, metric or footage marked
320 degrees
111 teeth, pitch 32
28mm
76mm
56mm
152mm
42°50'
16°24'
18°41'
7°05'
344 x 143mm
126 x 54mm
