Mounting the Hood
10. Install duct work and duct tape.
11. Unwrap the blue antenna wire and position it behind the duct cover from step 13. There is no need
to secure it.
12. Power up hood and check for leaks around duct tape.
13. Place telescopic duct covers onto hood and extend inner (top) duct cover upwards and secure to
duct cover bracket using (2) M4 x 8" screws.
NOTE: If using hood in recirculating mode you must secure the air diverter plate onto wall before
installing duct work and duct covers. Turn to page 19 for more details.
