Remove from below the vehicle any protective sealant from the points of contact between the shell and the tow bar; then paint the
uncovered parts with rust preventer. The holes for the tow bar's fixing need to be done.
1. Disassemble the rear bumper.
2. Place drawbeam "A" on the vehicle's middle side in support of the vehicle's rear chassis and middle spar.
3. With reference to points "1" drill some belt loops with a bit of Ø 11 mm and broaden gradually with a bit of Ø 18 mm only
the side where the sparer will be fitted.
4. With reference to the just bored holes "1", insert screws and then fix interjecting the sparers.
5. With reference to holes "3" drill some holes with a bit of Ø 11 mm; insert screws and then fix.
6. In correspondence to holes "2" insert screws and then fix.
7. Tighten all bolts and nuts with a tightening torque as shown in the enclosed layout.
8. Connect the wiring to the socket (usually given apart), following the car booklet's instructions "use and maintenance" as
shown in the enclosed wiring kit layout.
9. Reassemble the rear bumper.
• Make sure that the tow bar is suitable for the vehicle before starting the installation. Verify also that the vehicle's towing
disposal quoted on the car registration is mentioned on the tow bar document. Otherwise ask for the appropriate office
(umbrarimorchi@umbrarimorchi.it) for explanations or updated documents.
• For safety, all work involving tow bar installation must be undertaken by skilled technicians.
• Damaged components must be replaced with manufacturer's spares parts by qualified staff.
• It is forbidden to make any modification or structural repair to the tow bar.
• The tow ball must be kept clean and lubricated. For added safety, his diameter (50 mm) must be checked at regular
intervals. If the tow ball measures less than 49 mm after selected readings across the diameter, the tow ball must be
replaced with a new one.
• After 1000 km of towing, check torque settings for nuts and bolts, in accordance with the table.

FITTING INSTRUCTIONS

SAFETY INSTRUCTIONS

USE AND MAINTENANCE

13154 • 1.0 • 06/07/2017 6
