13 Main camera lens
14 Camera light
15 Headset jack
16 Wi-Fi/GPS/Bluetooth antenna area
17 Second microphone
18 Port for charger/USB cable
19 Memory card slot cover
20 NFC detection area
Assembly
A protective plastic sheet is attached to the screen. You should peel off this sheet before
using the touchscreen. Otherwise, the touchscreen might not function properly.
To insert the micro SIM cards
1
Insert a fingernail into the gap between the micro SIM card slot cover and the
device, then detach the cover.
2
With the gold-coloured contacts facing down, insert the micro SIM cards into their
slots until you hear a locking sound.
3
Re-attach the micro SIM card slot cover.
If you are using only one SIM card with your device, you must place this SIM card in SIM tray
1.
To insert a memory card
