ACIS Vipool Manuel De L'utilisateur page 10

FILTRES BOBINES SIDE
SIDE FIBERGLASS FILTERS
n° Vanne 6 voies 1.5'' / 6 ways valve 1.5''
1
Poignée Handle
2
Goupille Handle axis
3
Rondelle Washer
4
Vis, écrou Screw, nut
5
Couvercle Cover
6
Joint rotor Rotor O'ring
7
Rondelle Washer
8
Joint Seal
9
Ressort Spring
10
Rotor Rotor
11
Joint Seal
12
Corps vanne Valve body
13
Réduction Reduction
14
Bouchon Plug
15
Manomètre Gauge
16
Joint Seal
17
Union Union
18
Ecrou Nut
19
Témoin de lavage Washer indicator
20
Bouchon vidange Drain plug
21
Coude Elbow
22
Ecrou Nut
23
Adaptation Adaptation
24
Joint Seal
25
Union Union
26
27
15 Rue des Marais 44310 ST Philbert de Gd Lieu – Tel. 02 40 59 95 35 – www.acis-france.com
1.5''
Vanne 6 voies 2'' / 6 ways valve 2''
Poignée
Goupille
Rondelle
Couvercle
Vis
Réduction
Bouchon
Manomètre
Joint
Adaptation
Union
Ecrou
Joint
Rondelle
Joint
Ressort
Rotor
Joint
Corps
Témoin lavage
Joint
Union
Ecrou
Joint
Bouchon vidange
Coude
Ecrou
Handle
Handle axis
Washer
Cover
Screw
Reduction
Plug
Gauge
Seal
Adaptation
Union
Nut
Seal
Washer
Seal
Spring
Rotor
Seal
Body
Washer indicator
Seal
Union
Nut
Seal
Drain plug
Elbow
Nut
10
2''
