About your Product

General Information

The Furrion Maximum Power Point Tracker
(MPPT) series controllers can increase
charge current by up to 30% compared
to conventional Pulse Width Modulation
(PWM) controllers. Furrion's sophisticated
three stage charge control system can be
configured to optimize charge parameters
to precise battery requirements. The unit is
fully protected against voltage spikes, over
temperature, reverse battery and reverse PV
connections. Automatic battery temperature
sensors are also available to further protect
and improve battery performance. The
sensor element is environmentally sealed
and encapsulated into a connection lug which
directly connects to the battery terminals.
Furrion MPPT charge controller includes
RV-C communication bus interface in
accordance with RV-C bus communication
protocol.

Key Features

● Compatible with 12V or 24V battery
system.
● Advanced maximum power point tracking
technology to optimize the battery
performance. High tracking efficiency of
99%.
● High open circuit voltage of PV input.
● Battery is active in low voltage state.
● Sealed, AGM and LiFePO4 Lithium battery
option.
● Economy (ECO) mode, automatic
recognition of day and night.
● Temperature compensation and
corrective charging.
● RV-C bus communication protocol.
● Reverse protection: Polarity reverse for
PV input and battery.
● Electronic protection: overcharging, over
temperature, over PV input power.
● Easy to assemble: simply slide the
controller into the Furrion Solar Charge
Controller Mounting Bracket (model
FSCC60PWM not included).
