O
M
PERATING
ANUAL
T
ECHNICAL SPECIFICATIONS
Output power
Subwoofer
Front loudspeaker each
Effect loudspeaker each
Centre speaker
Mains voltage
Loudspeakers
Subwoofer
Front loudspeaker
Effect loudspeaker
Centre speaker
Accessories
Batteries
Loudspeaker cable
Dimensions (in mm)
Amplier
Subwoofer
Centre speaker
Satellite loudspeakers each
Weight
21 kg
O
PERATING ELEMENTS AND DISPLAYS
Amplier front panel
1. STANDBY button
2. LED display
3. Volume adjustment
4. Headphone output
5. DVD/5.1 button
6. VCR button
7. MD/CD button
8. AUX button
9. SOUND MODE button
10. CEN.MODE button
11. DSP button
12. BYPASS button
13. Treble
14. Bass
Amplier rear panel
15. SW OUT
16. AUX input jacks
17. MD/CD input jacks
35 W
30 W
30 W
30 W
230 V ~ 50 Hz
6.5" woofer
Ø 76 mm (3) 4 Ohm
Ø 76 mm (3) 4 Ohm
Ø 76 mm (3) 4 Ohm
2 x AAA 1.5 V
1 x 5 m (centre speaker)
2 x 5 m
2 x 14.5 m (front and effect loudspeakers)
430 (B) x 340 (T) x 128 (H)
260 (B) x 355 (T) x 380 (H)
360 (B) x 146 (T) x 120 (H)
120 (B) x 100 (T) x 180 (H)
90
