operation. Do not switch off before you disconnect the battery from the model!
Controller functions
No.
1 Left Stick
2 Right Stick
3 Trim A
4 Trim B
5 Trim C
6 Trim D
7 2.4GHz Antenna
8 Power Switch On/Off
9 Status LED
10 Light button
11 Flight mode button
12 Aileron/Rudder button Sets the pan flight on the left or right stick
3 Channel / 4
13
Channel Button
14 Video Button*
15 Photo Button*
16 Flip Button
17 Gasmode- Button
*Camera not included
www.acme-online.de
Button and
Description
Mode 1: Forwards/backwards; Left/Right- Turn
Mode 2: Gas; Left/Right- Turn
Mode 3: Forwards/backwards; Left/Right flight
Mode 4: Gas; Left/Right flight
Mode 1: Gas; Left/Right flight
Mode 2: Forwards/backwards; Left/Right flight
Mode 3: Gas; Left/Right turn
Mode 4: Forwards/backwards; Left/Right turn
Mode 2+4: no function
Mode 1+3: Forwards/backwards trim
Mode 3+4: Left/Right/Aileron trim
Mode 1+2: Left/Right/Rudder- trim
Mode 2+4: Forwards/Backwards trim
Mode 1+3: no function
Mode 3+4: Left/Right/Rudder- trim
Mode 1+2: Left/Right/Aileron trim
Controllersignal
On/Off button
(1) Fast flashing: Not paired yet
(2) Permanent Light: Paired
Light On/Off
3 Modes: Low, Medium, High
3 Channel: Without pan
4 Channel: With pan (factory setting)
Starts the video recording
Startet the photo recording
Performs a flip
Sets the gas on the left or right stick
ACME the game company
