5 CONNeCTING

Connect the product to your computer, notebook and so on.
Depending on the model the connectors can vary.
2 x 3.5 mm stereo plug (3 pole)
The green plug is used for sound reproduction. Plug it into the
appropriate green socket of your device, or into a socket of your
device which is marked with a headphone symbol.
The pink plug is used for sound generation. Plug it into the
appropriate socket of your device, or into a socket of your device
which is marked with a microphone.
3.5 mm stereo plug (4 pole)
Plug it into the appropriate audio socket of your device.
USB plug
Plug it into a data USB socket of your device.
6 INSTALLING (95112 ONLY)
The product works after plugging it in.
When the device does not work by plug and play,
select "USB Audio device" or the appropriate
connections in system control mode.
Start - Adjustments - Sounds and Audio Devices - Audio
