NOTICE!
•
Mount the vacuum cleaner in a dry place.
•
Do not mount the vacuum cleaner in an area which is subject to
high temperatures.
•
Do not bend the connection cable round sharp edges or cor-
ners. Keep the connection cable away from heated surfaces.
•
To install the vacuum cleaner, the wall thickness must be a mini-
mum of 10 mm and a maximum of 25 mm.
•
Ensure there is a socket nearby which can be used to supply the
vacuum cleaner with power. Do not use extension cables.
•
If the vacuum cleaner is being installed in small spaces with poor
ventilation (e.g. cabinet), then an air outlet and an air outlet grille
with a cross-section of 70 mm must be installed in order to trans-
port warm air generated by the device outside.
➤ Ensure that the dust bag and the motor filter are in place.
➤ Check the vacuum cleaner works prior to installation.
A
NOTICE!
The bolts on the housing must not be screwed out completely
because they are fitted with a spring mechanism.
➤ Mount the vacuum cleaner (fig. 4, page 4 to fig. 0, page 5).
I
NOTE
The mounting connectors (fig. 3 1, page 4) need to be glued on
the device-side using a standard adhesive. The screw connectors
(fig. 3 2, page 4) are screwed into the connection hose and
inserted into the mounting connectors.
➤ Mount the hose socket and route the connection hose (fig. a, page 5, and
fig. b, page 5).
Connecting electrical power to the vacuum cleaner
➤ Connect the orange-coloured 24 Vg cables on the rear of the device to the
contacts on the hose socket (fig. c, page 6).
!
WARNING!
Danger of electrocution and serious injury.
Only use the 230 V connection cable supplied.
➤ Connect the 230 V connection cable to a suitable socket (fig. d, page 6).
