ENGLISH

1. THE REAR PANEL

• POWER (5V DC) : The power port is to connect the DC power adapter.
• WAN : The WAN Ethernet port is to connect your ASDL/Cable modem.
• Ports 1- 4 : This is to connect networked devices, such as PCs, ftp servers or anything else
you want to put on your network.
• Reset Button : If you would like to load default settings, press the reset button and hold it for
5 ~ 6 seconds. It will load the factory default settings for the device. Do not press the reset
button unless you want to clear the current data.
5 WBR 244
