ENGLISH
OPERATION MANUAL
®
Thank you for buying this JB Systems product. To take full advantage of all possibilities and for your own
safety, please read these operating instructions very carefully before you start using this unit.
FEATURES
This unit is radio-interference suppressed. This product meets the requirements of the current European and
national guidelines. Conformity has been established and the relevant statements and documents have been
deposited by the manufacturer.
 This device was designed to produce decorative effect lighting and is used in light show systems.
 The best of both worlds: this fantastic effect uses a 30mW green laser + 80mW red laser in combination
with a nice water wave LED projector.
 Using special grating technology the beams are split-up in a lot of separate laser beams pointing in all
directions to create an amazing, room filling effect.
 Plug & play: no expensive controllers needed!
 Separate rotation controls for lasers and LED projector.
 Strobe control for each laser + dimmer for the LED projector
 Perfect for projections on walls and ceilings in bars, clubs, discotheques, hotels, etc
 Key actuated on/off switch for additional safety
 Complies to EN/IEC 60825-1 for Laser Safety

BEFORE USE

 Before you start using this unit, please check if there's no transportation damage. Should there be any, do
not use the device and consult your dealer first.
 Important: This device left our factory in perfect condition and well packaged. It is absolutely necessary
for the user to strictly follow the safety instructions and warnings in this user manual. Any damage caused
by mishandling is not subject to warranty. The dealer will not accept responsibility for any resulting defects
or problems caused by disregarding this user manual.
 Keep this booklet in a safe place for future consultation. If you sell the fixture, be sure to add this user
manual.
Check the contents:
Check that the carton contains the following items:
 Operating instructions
 Lounge Laser Unit
 2 keys (for key switch)
 Power Supply

SAFETY INSTRUCTIONS:

CAUTION
The lightning flash with arrowhead symbol within the equilateral triangle is intended to alert the
use or the presence of un-insulated "dangerous voltage" within the product's enclosure that may
be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within the equilateral triangle is intended to alert the user to the presence
of important operation and maintenance (servicing) instructions in the literature accompanying
this appliance.
This symbol means: indoor use only
This symbol means: Read instructions
This symbol means: Safety Class II appliance
JB SYSTEMS
®
OPERATION MANUAL
CAUTION: To reduce the risk of electric shock, do not
remove the top cover. No user-serviceable parts inside.
Refer servicing to qualified service personnel only.
1/29 LOUNGE LASER
ENGLISH
This symbol determines: the minimum distance from lighted objects. The minimum distance
between light-output and the illuminated surface must be more than 1 meter
 To protect the environment, please try to recycle the packing material as much as possible.
 To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
 To avoid condensation to be formed inside, allow the unit to adapt to the surrounding temperatures when
bringing it into a warm room after transport. Condense sometimes prevents the unit from working at full
performance or may even cause damages.
 This unit is for indoor use only.
 Don't place metal objects or spill liquid inside the unit. Electric shock or malfunction may result. If a foreign
object enters the unit, immediately disconnect the mains power.
 Don't cover any ventilation openings as this may result in overheating.
 Prevent use in dusty environments and clean the unit regularly.
 Keep the unit away from children.
 Inexperienced persons should not operate this device.
 Maximum save ambient temperature is 40°C. Don't use this unit at higher ambient temperatures.
 Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging
and servicing.
 Always unplug the unit when it is not used for a longer time or before to start servicing.
 The electrical installation should be carried out by qualified personal only, according to the regulations for
electrical and mechanical safety in your country.
 Check that the available voltage is not higher than the one stated on the rear panel of the unit.
 The power cord should always be in perfect condition. Switch the unit immediately off when the power cord
is squashed or damaged. It must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
 Never let the power-cord come into contact with other cables!
 In order to avoid a hazard, the unit shall only be used with the AC-adaptor delivered with it. If the AC-
adaptor is damaged, a same model adaptor shall be used only.
 Always use an appropriate and certified safety cable when installing the unit.
 In order to prevent electric shock, do not open the cover. There are no user serviceable parts inside.
 Never repair a fuse or bypass the fuse holder. Always replace a damaged fuse with a fuse of the same
type and electrical specifications!
 In the event of serious operating problems, stop using the fixture and contact your dealer immediately.
 The housing and the lenses must be replaced if they are visibly damaged.
 Please use the original packing when the device is to be transported.
 Due to safety reasons it is prohibited to make unauthorized modifications to the unit.
Important: Never look directly into the light source! Don't use the effect in the presence of persons suffering
from epilepsy.
LASER SAFETY INSTRUCTIONS:
 According to the EN 60825-1:1994 + A1:2002 + A2:2002 regulations, this laser falls under the
classification 3B. Direct eye exposure can be dangerous.
DANGER: LASER RADIATION !
Avoid direct eye exposure! Laser radiation can cause eye damage
and/or skin damage. All protective measures for a safe operation of
this laser must be applied.
 This product is a so-called show laser, emitting radiation with a wavelength spectrum between 400 and
700 nm and producing lighting effects for shows.
 Due to the construction of this laser, the beam is moved so fast, that it can only hit the eye very short. This
is why the use of this laser for a Laser-Light-Show can be regarded as save.
 Never direct the laser beam to people or animals and never leave this device running unattended.
 This laser may only be used for shows. The operation of a class 3B show laser is only allowed if the
operation is controlled by a skilled and well-trained operator.
 Depending on the classification, operating a laser product can produce laser radiation that may cause
permanent eye damage and/or skin damage. The legal instructions for using a laser product vary from
