CHASSIS GROUND
*ALARM RELAY
*WARN RELAY
*FAULT RELAY
*Please See Figure 18
* PLEASE SEE FIGURE 2-J
For Relay Protect i on
FOR RELAY PROTECTION
Circuits
CIRCUITS
Power Supply
-
+
COM.
1 10
COM.
2 9
+24V DC
3 8
+24V DC
4 7
5 6
O - 20 mA
6 5
ALARM TEST
7 4
RESET
8 3
DATA -
9 2
DATA +
10 1
RS485
Modbus 1
Figure 17: Bornes de champ FL3100H & FL3101H
Figure 18: Boîtier et socle du détecteur
18
Modèles FL3100H/FL3101H
UNIT #2
(IF POWERED IN SERRIES)
Optional Modbus 2
CONTROL
Optional HART
DEVICE
PLC, DCS, ETC
NORMALLY OPEN SWITCH
NORMALLY OPEN SWITCH
COM.
COM.
