General Monitors FL3100H Manuel D'instructions page 24

Modèles FL3100H/3101H
6.2[157.5]
1.50[38.1]
.75[19.1]
2X 3/4 NPT ENTRY
Figure 15: Dessin d'encombrement des modèles FL3100H et FL3101H
5.5
[139.7]
5.0[127.0]
4X M6 X 1
2.94[74.7]
6.2[157.5]
1.63[41.4]
.75[19.1]
1.67[42.4]
Figure 16: Dessin d'ensemble FL3100H et FL3101H
