PARTS LIST

N Description
o.
1 Extension bar
2 Base
3 Butterfly screw
4 Plum blossom rubber foot
5 Hex bolt
6 Stand bar
7 Friction plate
8 Rebounding plate board
9 Limit clamp
10 Screw
Spring washer
Flat washer
11 Lock spring
12 Hex screw
13 Rebounding plate board
14 Screw
Spring washer
Flat washer
15 Disk lock pin
16 Round pin
17 Rebounding plate spring
18 Operating handle
19 Rebounding plate
20 O-style seal ring
21 Disk lock plate
22 Disk
23 Disk pointer
24 Screw
Spring washer
Flat washer
25 Screw
Flat washer
26 Plastic insert
27 Flat washer
28 Hex nut
29 Bend arm label
30 Hex screw
31 Bend arm
32 Knob
33 Pull rod locking compression
spring
34 Flat washer
35 Self-restraint flat washer
36 Back lock hand wheel
37 Hex nut
38 Flat washer
39 Lock spring
40 Screw
41 Hexagon thin nut
42 Bend arm pointer
44 Hex screw
Spring washer
Flat washer
45 Fence
16
N Description
o.
46 Butterfly screw
47 Clamp rod component:
Clamp rod (solid)
Hand wheel
Butterfly screw
Clamp mass
Clamp slice
Split washer
48 Screw
49 Linear bearing press plate
50 Quakeproof washer
51 Linear bearing
52 Pull rod (no collision slot)
53 Pull rod (have collision slot)
54 O-style ring
55 Back cover
56 Tapping screw
57 Wire clip (big)
58 Hex screw
59 Handle bail
60 Self-lock pin spring
61 Hex screw
62 Elastic round pin
63 Hex screw
64 Stand bar
65 Limit screw
70 Connecting rod
71 Connecting rod screw
72 Hex nut
73 Small hood
74 Big hood
75 Hex screw
Flat washer
76 Plum blossom screws
77 Coil spring
78 Transparent cover
79 Connect plate
80 Screw
81 Brush holder
82 Carbon brush
84 Square housing
85 Screw
Spring washer
Flat washer
86 Stator
87 Tapping screw
88 Windshield
89 Rolling bearing
90 Rotor
91 Bearing shaft
92 Rolling bearing
93 Lock flat spring
94 Lock
96 Torsional spring
N Description
o.
97 Lateral pin
98 Housing
99 Hex screw
100 Dust band
101 Hex screw
102 Lock washer
103 Rolling bearing
104 Bearing spring shaft
105 Big gear
106 Front cover
107 Rolling bearing
108 Output shaft
109 Woodruff key
110 Bearing cover
111 Screw
Spring washer
112 Inner press plate
113 Blade
114 Outer press plate
115 Screw, sinistral with flat washer
116 Two foot switch spring
117 Micro switch spring
118 Switch button
119 Up handle
120 Tapping screw
121 Handle
122 Tapping screw
123 Screw
124 Tapping screw
125 Cable tension disc
126 Cable
127 Cable sheath
128 Terminal connector
129 Down handle
130 Battery cover
131 Conducting plate
132 General battery box spring
133 Battery box switch
134 Screw
135 Flat washer
136 Battery box
137 Switch cover down
138 Tapping screw
139 Laser seat
140 Laser positioning plate
141 Nut
142 Screw
143 Screw
144 Screw
145 Battery
146 Laser head
147 Copper sheet
148 Hex spanner
