Front Panel

1
1. Input Jack Sockets
Plug your guitar into the HIGH or LOW input. The 'HIGH' input will give you more gain and out-
put volume and the 'LOW' input will be quieter and have more clean headroom.

2. Volume Control

This controls the preamp volume/gain. It can be used in conjunction with the 'Master Volume'
control to create the perfect balance between pre/power amp distortion and overall output level.
Turn clockwise for more gain.
3. Treble Control
This controls the high frequencies in your sound—from soft and smooth when turned down
(counter clockwise) to bright and cutting when cranked (clockwise) and all points in-between.
4. Mid Boost Switch
The Mid boost switch is a mid/gain boost. This specially voiced mod is ideal for players wanting
to boost their solos or leads. You can also leave this switch permanently activated dramatically
changing the sound of your amp and allowing you to take your search for tone even further!
5. Mid Control
This controls the mid frequencies in your sound. Turn anti clockwise for a scooped spacious
sound or turn clockwise for a more focused and full bodied tone.

6. Bass Control

This controls the low frequencies in your sound—from thin and light when turned down (counter
clockwise) to warm and heavy when turned up full (clockwise) and all points in-between.
7. Reverb Control
This allows you to control the level of the reverb from a subtle shimmer to luscious 'surf' style
waves of sound. This control is very sensitive and was designed this way so any amount of
reverb can be obtained without having to push the preamp hard.
4
