CBBG 400 PLUS
apart and cause injuries.
SWITCHING ON AND OFF
To start the power tool, push the on/off switch
ƒ
(4) into position "I".
To switch off the power tool, push the on/off
ƒ
switch (4) into position "0".

WORKING ADVICE

Switch the power tool on before bringing the
f
workpiece into contact with it and only switch
the power tool off after you have removed the
workpiece. The workpiece can move suddenly.
Never reach into the power tool grinding
f
wheel when it is running. This can lead to seri-
ous injuries.
Wear a work apron. Ensure that no persons
f
are at risk due to flying sparks. Remove com-
bustible materials from the surrounding area.
Flying sparks are created when sanding metals.
Use silicon carbide grinding discs C (accessory)
when working carbide (TC) workpieces.
Place the workpiece you intend to grind onto the
ƒ
tool rest (5) and press it lightly against the grind-
ing wheel. To achieve optimal grinding results,
move the workpiece gently back and forth. This
also ensures that the grinding wheel is worn off
evenly.
Cool off the workpiece in water at intervals.
ƒ
SANDING
To sand a workpiece:
Before starting the machine, adjust the angle of the
f
tool rest so your workpiece is supported and the
area you wish to sand is parallel with the sanding belt
as illustrated (in Fig 4).
With the machine plugged into power, stand to the
f
side of the grinding wheel and move the red switch
to the ON position.
Allow the machine to run for at least 1 minute to
f
make sure that the grinding wheel is not going to fly
apart and injure you, then move to the front of the
machine.
figure 4
Grasp the workpiece tightly and properly support it
f
on the tool rest.
Press the workpiece evenly against the sanding belt
f
with light pressure (see Fig 5 and 6). DO NOT press
hard. Let the rotation of the belt do the work.
Remove your workpiece regularly to check the
f
progress the sander has made. Remember you can
always remove more material but you cannot add it.
When you are finished sanding, move the red switch
f
to the OFF position. DO NOT continue sanding and
DO NOT manually stop the sanding belt with your
workpiece.

TRANSPORT

Remove all accessories that cannot be securely
ƒ
fitted to the power tool.
Wind up the network cable completely and tie it
ƒ
together.
To lift or transport the power tool, hold it from
ƒ
below by the two protective guards.

MAINTENANCE AND CLEANING

Pull the plug out of the socket before carrying
f
out any work on the power tool.
To ensure safe and efficient operation, always
f
keep the power tool and the ventilation
slots clean.
In order to avoid safety hazards, if the power sup-
ply cord needs to be replaced, this must be done
by FF Group or by an after-sales service center that
is authorised to repair FF Group.

REPLACING WHEELS

WARNING! The hazards of using a damaged
wheel include flying chunks of sharp abra-
sive material that could cause serious inju-
ry or death. Inspect every grinding wheel
before it is mounted and DO NOT use a da-
maged grinding wheel!
The wheel guard assembly must be removed in or-
der to mount or dismount a grinding wheel.
To remove/mount a wheel:
Disconnect the grinder from the power supply.
f
Remove the head screws and nuts that go through
f
the outer guard. Take off the outer guard and the
rim guard.
Use a wrench on the nut that holds the wheel on
f
the arbor. Hold the wheel to prevent it from turning
with your other hand. The grinding wheel arbor has
a left-handed thread. Loosen the nut by turning it
clockwise.
Remove the outer wheel flange and paper disc. Pull
f
the wheel free from the arbor. There will also be a
paper disc and a wheel flange on the back side of the
English | 9
figure 5
figure 6
