DONGLE USB WMBUS AMR - Mode d'emploi - User guide V1.3
DECLARATION OF CONFORMITY
DECLARATION OF CONFORMITY
We
ADEUNIS RF,
283 rue LOUIS NEEL, 38920 CROLLES, France
declare under our own responsibility that the products:
Name
DONGLE USB Wireless M-Bus AMR
Reference(s)
ARF8020Ax
to which this declaration refers conforms with the relevant standards or other standardising documents:
•
EN 300 220-2 (v2.3.1) (2010-02)
•
EN 60950-1 (2001) + A11 (2004)
•
EN 301 489-1 (v1.8.1) (2008-04)
•
EN 301 489-3 (v1.4.1) (2002-08)
•
EN 62311 (2008)
Selon la directive RTTE 99/5/EC
Notes:
•
According to the 1999/519/EC «RF signal» recommendations, a minimum distance of 10cm between the product and the body is required.
•
Receiver class (if applicable): 3
Crolles, 5 March 2014
1. Présentation
The Wireless M-Bus USB dongle from Adeunis RF is a ready-to-use device which allows to send and receive radio frames using the Wireless M-
Bus protocol.
The implementation of the receiver is immediate («plug & play» system).
This dongle is power supplied by the device to which it is connected and allows the collection of the data transmitted in T1, T2, R1, R2, S1, S1-m
or S2 mode.
Its 868MHz integrated antenna contributes to its extremely small footprint, while maximizing performance.
Our Wireless M-Bus solution provides a full compatibility with EN 13757-4: 2005 standard.
The combination of products in the Adeunis RF AMR range allows you to create an independent ecosystem to ensure the emission, transport
and collection of consumption indexes using Wireless M-Bus protocol. .
2. Technical specifications
Technical specifications
Communication
Dongle USB AMR configuration
Radio data rate
USB data rate
Frequency channel
Programmable RF output power
Sensitivity
Wireless M-Bus protocol all modes supported S1, S1-m, S2, T1, T2, R2 ,S2, T2
Through dedicated commands
4.8kbps (mode R), 32.768 kbps (mode S) and 100 kbps (mode T)
115.2 kbauds
10 (mode R) and 1 (mode S and T)
Up to 25 mW (14 dBm)
T mode: down to -110 dBm @ BER10
S mode: down to -112 dBm @ BER10
R mode: down to -117 dBm @ BER10
Hervé Vincent, CEO
(Data rate 100kbps)
-3
(Data rate 32kbps)
-3
-3
(Data rate 4.8kbps)
Page
16
of 23
