Technical Data

LazyLiner Pro (6.0 Hp)
Engine
Engine oil type
Weight
Dimensions (L x W x H, seat in raised position)
145 cm x 66 cm x 107 cm
Maximum speed
Forward
Reverse
Sound pressure
Vibration level (with attached line striping equipment)
< 2.5 m/s² (right and left hand)
Max. tire pressure
Construction
All steel welded construction frame and guards, engine protection bar and steel fenders with
industrial powder coat
Drive
C ast iron Hydrostatic transmission for forward and reverse operations
O ne gas pedal (forward/backward)
T rack control drive differential
D ouble row rolling chain drive
Mobil 1™ 15W50 full synthetic oil (4 quarts)
Hydraulic operating pressure
Operating temperature
+10°C and +40°C (+50ºF and +104ºF)
Relative humidity
50%, by +40°C (+104°F) (A higher relative humidity poses no problem at lower temperatures.)
Operating altitude
max. 3000m (9843') above sea level
Parking brake
Manual parking brake
Hitch
For installation on Titan and Graco line striping equipment
Seat
Deluxe, high upholstered back with adjustable comfort control and weight sensor for safety shut
off
* Measured at the height of the seat position.
LazyLiner Pro • Elite
Subaru, 6.0 Hp, pull start
SAE10-30W (0.6 l)
118 kg
0-16 KM/h
0-11 KM/h
85 dB*
25 PSI (1.7 bar)
2700 PSI (186 bar)
GB
LazyLiner Elite (7.0 Hp)
Subaru, 7.0 Hp electric start, 16A/200W
SAE10-30W (0.6 l)
127 kg
157 cm (bumper bar installed) x 74 cm x 107 cm
0-16 KM/h
0-11 KM/h
85 dB*
< 2.5 m/s² (right and left hand)
25 PSI (1.7 bar)
2700 PSI (186 bar)
3
